Honda / Acura J35 Connecting Rods Features:
1. Manufactured from high strength 4340 Chrome Moly Steel
2. Designed and fully processed by CNC machine
3. Three std design for various application: H-beam, I-beam and X-beam
4.100% X-rayed, sonic tested and magnafluxed to insure quality
5. All big and small ends are finished with honing machine
6. Small ends came with Alum/Sil Bronze bushing(QAL10-3-1.5) suitable for the floating piston pin
7. All surfaces shot peened and stress relieved
8. Packaged in balanced per set: end to end +/- 1 gram
- Make/Engine
- ——— Connecting rods ———(335)
- ▶ Acura & Honda Rods(46)
- ▶ Audi & VW Rods(41)
- ▶ Buick Rods(6)
- ▶ BMW Rods(25)
- ▶ Chevrolet Rods(51)
- ▶ Chrysler & Dodge Rods(12)
- ▶ Fiat Rods(7)
- ▶ Ford Rods(14)
- ▶ Harley Davidson Rods(4)
- ▶ Isuzu Rods(3)
- ▶ Mazda Rods(7)
- ▶ Mitsubishi Rods(10)
- ▶ Nissan Rods(24)
- ▶ Opel/Vauxhall Rods(11)
- ▶ Subaru Rods(6)
- ▶ Suzuki Rods(3)
- ▶ Toyota Rods(40)
- ▶ Other Rods(25)
- ——— Crankshafts ————(20)
- ——— Pistons ——————(11)
- ——Connecting rods bolts——(3)
- ——— Gallery ——————(3)
- Latest Product
- News
Honda / Acura J35 Connecting Rods - Hurricane Speed and Performance
Hurricane High Performance connecting rods - Process of machining rods
Main rods includes Chevy,Ford, Harley Davidson, VW & Audi, Opel, Honda, Nissan,Subaru, Mitsubishi, Toyota, Isuzu, Suzuki, Mazda, Buick, BMW, Chrysler & Dodge, Fiat
Here in the following process of pictures are the 13 major operations undertaken in the production of Hurricane Speed&Performance:Hurricane Factory VW Air Cooled Forged Steel Crankshaft Info
Hurricane factory manufactured in a wide variety of strokes with either VW or Chevy journals to fit your exact engine configuration. All of hurricane ...Hurricane Connecting Rod Features - Various Beam Designs
With many years experience of designing, developing , engineering and manufacturing in the connecting rods fields, Hurricane has ability to handle different customers needs on connecting rods designs . Except connecting rods shoulder and small end, Hurricane also can build various connecting rods beam style .4340 STEEL, TITANIUM AND ALUMINUM CONNECTING RODS
Weight. Strength. Balance. When it comes to rod selection, which is more important? Through advances in technology and automation, it is now possible to provide three kinds of connecting rods in one factory (Hurricane Speed and Performance), 4340 steel, Titanium and Aluminum.
- Certifications
- Contact us
- Hurricane is manufacturer of high performance automotive engine parts. We specialize in the rotating assembly and related components; crankshafts, rods and pistons. All our products are developed and produced in our factory on advanced CNC machinery. Our staff of engineers and skilled craftsmen are dedicated to giving your company the edge in both quality and price. Browse our website or arrange a factory tour by emailing: marketing@hurricane-rod.com.cn . Contact Now
4340 Connecting rod H-beam for Honda D16A
- Competitive Price
- Quality Assurance
- MOQ：80pieces
- Delivery Time: If the goods are in stock , the delivery time is 1-3 days.
- If the goods are not in stock , the delivery time is 60-65 days .
- Payment Terms : T/T , Paypal , Western Union
Brand: Hurricane
Engine: Honda D16A
Part Type: Connecting Rods
Center to Center Length: 137.01mm/5.394"
Big End Bore Diameter: 48.01mm/1.890"
Big End Width: 25.86mm/1.018"
Small End Bore Diameter: 19.02mm /0.749"
Small End Width: 18.19mm/0.716"
Beam Style: H-beam
Connecting Rod Bolt Diameter: 3/8"
Quantity :4pcs/set
Approximate Connecting Rod Weight: 469g/piece
Advertised Horsepower Rating: 750hp
Material: Forged 4340 steel
Connecting Rod Finish: Shot-peened, Polished
Pin: Bronze wrist pin bushings
Wrist Pin Style: Floating
Cap Retention Style: Cap screw
Weight Matched Set: Yes ,Balanced +/- 1g
Magnafluxed: Yes
Private Label: Yes ,available
Custom design: Yes, accept
-Built from high tensile 4340 forged steel material
Engine: Honda D16A
Part Type: Connecting Rods
Center to Center Length: 137.01mm/5.394"
Big End Bore Diameter: 48.01mm/1.890"
Big End Width: 25.86mm/1.018"
Small End Bore Diameter: 19.02mm /0.749"
Small End Width: 18.19mm/0.716"
Beam Style: H-beam
Connecting Rod Bolt Diameter: 3/8"
Quantity :4pcs/set
Approximate Connecting Rod Weight: 469g/piece
Advertised Horsepower Rating: 750hp
Material: Forged 4340 steel
Connecting Rod Finish: Shot-peened, Polished
Pin: Bronze wrist pin bushings
Wrist Pin Style: Floating
Cap Retention Style: Cap screw
Weight Matched Set: Yes ,Balanced +/- 1g
Magnafluxed: Yes
Private Label: Yes ,available
Custom design: Yes, accept
-Built from high tensile 4340 forged steel material
-H-beam design to reduce weight
-Shot peening to achieve maximise fatigue strength and material durability
-Designed and processed by CNC machine
-The big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Come with bronzed bushing for the floating piston pin
-The big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Come with bronzed bushing for the floating piston pin
-Weight matched sets +/- 1gram
Hurricane produce racing connecting rods for all kinds of Honda engines , include :
If you can not find the rods which you want on our websites, please feel free contact us .
Tag:4340 connecting rods honda, Honda connecting rods, D16 forged internals, Honda D Series Rods, H-beam connecting rod, honda h beam connecting rod, honda forged rods, H-Beam Chromoly connecting rods, HUR5-001Y5394 honda forged rod D16A, HUR5-001Y5394 Honda D16A Connecting Rod
