Honda / Acura K Series K24 TSX K24A K24Z Element CRV CONNECTING RODS

Made from 4340 steel material

Competitive Price

100% fully CNC machine

Quality Assurance

MOQ：100pieces

Delivery Time: If the goods are in stock , the delivery time is 1-3 days.

If the goods are not in stock , the delivery time is 60-65 days .

Payment Terms : T/T , Paypal , Western Union

Keywords:Honda K Series Connecting Rods

Hurricane I Beam Connecting Rods for Honda Engines

K24 5.985" Performance Connecting Rod

Honda performance connecting rod factory in China

4340 aircraft steel Connecting Rods | K Series Parts

Display Parameters Contact Now

Product Details

Brand: Hurricane
Engine: Honda K24 K24A
Part Type: Connecting Rods
Center to Center Length: 151.99mm/5.984"
Big End Bore Diameter: 51.006mm/2.008"
Big End Width: 19.8mm/0.780"
Small End Bore Diameter: 22.015mm /0.867"
Small End Width: 19.8mm/0.780"
Beam Style: I-beam
Connecting Rod Bolt Diameter: 3/8"
Approximate Connecting Rod Weight: ~g/piece
Advertised Horsepower Rating: 800hp
Quantity: Sold as 4 pieces per set
Material: Forged 4340 steel
Connecting Rod Finish: Shot-peened, Polished
Pin: Bronze wrist pin bushings
Wrist Pin Style: Floating
Cap Retention Style: Cap screw
Weight Matched Set: Yes ,Balanced +/- 1g
Magnafluxed: Yes
Private Label: Yes ,available
Custom design: Yes, accept

K24 5.985" Performance connecting rod Description

If you are looking for Honda performance connecting rod factory in China, Hurricane speed and performance will be your best choice. Our factory provide various kinds of designs and strong performance connecting rods for Honda B, D, F, K, H, J and L series race engines. Our Honda K Series Connecting Rods quality is top notch, and the price is totally reasonable. They could come with ARP Bolts, and the quality control is industry leading with fully CNC machine, there is a short video of Hurricane company. If you are unsure if this is the correct rod for you, please contact us today to help you put together the parts list for your next build!

To view more honda series connecting rods we done, you can find easily at our catalog page.

Our Honda K24 connecting rods suit for following applications:

K24A	2002–2008 Honda Accord 24TL and Type-S 2008–2013 Honda Accord Type-S 2003–2013 Honda Odyssey Absolute
K24A(Eco)	2003–2005 Honda Element 2003–2013 Honda Odyssey 2003–2005 Honda Stepwgn Spada 24T 2004–2013 Honda Elysion 2006–2009 Honda Edix 24S 2005–2016 Honda CR-V
K24A1	2002–2006 Honda CR-V
K24A2	2004–2005 Acura TSX 2006–2008 Acura TSX
K24A3	2003–2007 Honda Accord 2003–2007 Honda Accord Euro
K24A4	2003–2005 Honda Accord (USDM) 2003–2008 Honda Odyssey 2003–2006 Honda Element
K24A8	2006–2007 Honda Accord 2007–2011 Honda Element 2008–2014 Honda Odyssey

Honda K Series Connecting Rods with featuring the benefits below:

1. Made from certified forging 4340 steel material.

2. All drawing, design, programming, machining, assemble, and QC performed in-house by qualified and experienced personnel over 20 years.

3. Machine to final rods, not need to machine any more when you get them.

4. Free assemble bolt from customers if necessary.

5. Full shot peening and polishing.

6. Accept custom design rods.

7. All sets balanced to a +/- 1 gram standard.

8. 100% made with fully CNC machine.

If you have any rods purchase plan, welcome to contact our sales team and the best price will be provided.

Honda Odyssey Track Car

Note: Picture from Pinterest.
