Audi 20V S2 S4 RS2 forged 4340 steel H beam connecting rods,155mm rod length

Competitive Price

Quality Assurance

MOQ：100pieces

Delivery Time: If the goods are in stock , the delivery time is 1-3 days.

If the goods are not in stock , the delivery time is 60-65 days .

Payment Terms : T/T , Paypal , Western Union

Keywords: Audi S2 RS2 2.2L 5 Cylinder rods

Audi 155mm forged steel connecting rods

Audi High performance H-beam connecting rods

Audi S2 S4 RS2 5Cyl connecting rods

Audi vw forged 4340 steel connecting rods

Display Parameters Contact Now

Product Details

Brand: Hurricane
Engine: Audi 20V S2 S4 RS2
Part Type: Connecting Rods
Center to Center Length: 155mm/6.102"
Big End Bore Diameter: 50.6mm/1.992"
Big End Width: 24.8mm/0.976"
Small End Bore Diameter: 20mm /0.787"
Small End Width: 24.8mm/0.976"
Beam Style: H-beam
Connecting Rod Bolt Diameter: 3/8"
Approximate Connecting Rod Weight: 580g per piece
Advertised Horsepower Rating: 800hp
Quantity: Sold as 5 pieces per set
Material: Forged 4340 steel
Connecting Rod Finish: Shot-peened, Polished
Pin: Bronze wrist pin bushings
Wrist Pin Style: Floating
Cap Retention Style: Cap screw
Weight Matched Set: Yes, Balanced within +/- 1g per set
Magnafluxed: Yes
Private Label: Yes, available
Custom design: Yes, accept

Audi S2 RS2 2.2L 5 Cylinder rods Description

Connecting rods have to be strong enough to handle the anticipated speeds and loads without bending or buckling under pressure. That is why Hurricane use strong 4340 material and fully CNC production line.

Those Audi 155mm forged steel connecting rods fits 20V S2 S4 RS2 engines. Round shoulder design improving clearance. Shot peened improved fatigue life. Premium bronze wrist pin bushings and High Quality Race Spec Hurricane 3/8 fasteners included. They are Designed for high-stress racing applications, and reach 800 Horsepower.

Technical Features of Hurricane Speed and Performance Connecting Rods:

H-Beam design providing extended rigidity under vertical load
One-Piece forging for great strength
Shot Peening for improved fatigue life
Magnaflux Inspection guarantees that the consistency of the forged material meets our high-quality standard
Multi Stage Heat Treatment for maximum strength, dimensional stability, and fatigue life.
CNC machining for superior tolerances, precise as much as 0.15mm
Center to center is maintained under 0.05mm tolerance
Finite Element Analysis (FEA) Computer generated stress analysis of con rods
Optimal balancing for weight matched sets of ± 1gram

Audi S2 RS2 Race Car

Note: Picture from Pinterest.

Hot Tags : H-beam connecting rod forged 4340 steel connecting rod for vw audi connecting rod HUR41-001H6102 Audi S4 155mm connecting rods
