Audi 2.7T H Beam Rods - Hurricane Speed and Performance
- Forged 4340 Steel
- Fully CNC Machine
- Quality Assurance
- Competitive Price
- Valid Lead Time
- MOQ: 100pieces
- Delivery Time: If the goods are in stock , the delivery time is 1-3 days.
- If the goods are not in stock , the delivery time is 90-95 days .
- Payment Terms : T/T , Paypal
- Keywords: Forged Connecting Rods Audi 154X21 - Fits 2.7T V6
- H-Beam Connecting Rods for Audi/VW V6 Engine 2.6L 2.8L 2.7T 154mm Conrods
- Audi B5 S4 2.7T Performance Connecting Rods
- AUDI 2.7TT 30v/2.8 12v H-Beam FORGED RODS
- Audi A4 B5 S4 A6 2.7L V6 Connecting Rod | Rods | Conrods
| Brand: Hurricane |  |
| Center to Center Length: 154mm/6.063" | |
| Big End Bore Diameter: 56.80mm/2.236" | |
| Big End Width: 20.12mm/0.792" | |
| Small End Bore Diameter: 21.005mm /0.827" | |
| Small End Width: 21.92mm/0.863" | |
| Beam Style: H-beam |
H-Beam Connecting Rods for Audi/VW V6 Engine 2.6L 2.8L 2.7T 154mm Conrods Features
| Connecting Rod Bolt Diameter | 5/16" |
| Approximate Connecting Rod Weight | ~gram |
| Advertised Horsepower Rating | 700hp |
| Quantity | Sold as 6 pieces /set |
| Material | Forged 4340 steel |
| Connecting Rod Finish | Shot-peened, Polished |
| Pin | Bronze wrist pin bushings |
| Wrist Pin Style | Floating |
| Cap Retention Style | Cap screw |
| Weight Matched Set | Yes ,Balanced +/- 1g |
| Magnafluxed | Yes |
| Private Label | Yes ,available |
| Custom design | Yes, accept |
Audi B5 S4 2.7T Performance Connecting Rods Description
● Forged 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
● Designed with professional team
● Processed by fully CNC machine
● All big and small ends are finished with honing machine
● Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
● 100% X-rayed, sonic tested and magnafluxed
● Multi-stage heat treated, HRC34-38
● Shot peened to relieve stress
● Come with the bronzed bushing suitable for the floating piston pin
